Item | Unit | GS6132 | |
Maximum turning diameter of bed | mm | Φ 320 | |
Maximum machining diameter | mm | Φ 300 | |
Maximum machining diameter of turret | mm | Φ 150 | |
Max length | mm | 500 | |
Maximum diameter of the bar | mm | Φ 40 | |
Spindle through-hole diameter | mm | Φ 52 | |
Spindle speed range | r/min | 100-2600 | |
Spindle nose form | ISO | A2-5 | |
Main motor power | kw | 3.0 | |
X axis | mm | 180 | |
Z axis | mm | 500 | |
X axis | mm | 6000 | |
Z axis | mm | 8000 | |
Turret station | Four-position electric turret | ||
Tailstock sleeve diameter | mm | 40 | |
Tailstock quill stroke | mm | 100 | |
Tailstock taper | ISO | Mohs 4th | |
Overall dimensions(L×W×H) | mm | 1600/1200/1500 | |
Machine weight | kg | 1400 |
Automatic front feeding method
Features:
Compact feeding mode structure, nesting reasonable, fast response, smooth and stable feed
Automatic evacuation material way
Features:
This feeding mode noise operation, the machine can keep operating under deformation of the workpiece is not bent, adaptation diameter 5 ~ 42mm, the length of the bar within 3m of batch processing.
Automatic feeding the upper way
Features:
This feeding method biggest feature is feeding the whole process does not take up the work area, you can arrange multiple knives for shaped pieces of processing, and multi-process machining complex parts.
Automatic mode vibration plate
Features:
This feeding method is the basis of the previous feeding methods to be optimized and improved for high-volume parts processing, reduce processing costs, save labor, each person can manage four or more machines, high degree of automation.
