GL-4.0DX
>>Anti-slip platform, distance adjustable to accommodate different vehicles.
>>The hydraulic cylinder is inside the fixed platform and is thus perfectly protected.
>>Safety systems against cable breakage, against obstacles during descend.
>>Connected steel cables to force the synchronized moving of platforms.
>>Secondary scissor lift for wheel free.
>>With sideslip plates and turntable spaces for wheel alignment.
GL4.0DX-1 with Italian pump station, Chinese hydraulic cylinder.
GL4.0DX-2 with Chinese pump station, Chinese hydraulic cylinder.
Technical data
Lifting capacity | 4000kg | First raising time | ≤80s |
Secondary lifting capacity | 2000kg | First lowering time | ≤70s |
First lifting height | 1550mm | Secondary raising time | ≤30s |
Secondary lifting height | 300mm | Secondary lowering time | ≤30s |
Min. height | 255mm | Motor power | 3kw/2.2kw |
Net weight | 1300kg | Power supply | 380v/50Hz |
